Description for Noctua NH-D9 DX-3647 4U Premium Quality Heat Sink for Intel Xeon LGA3647 (Brown)-CLR-0159
- Noctua NH-U9S DX is a high-performance LGA3647 CPU cooler with dual 92 mm PWM fans, four 6 mm heatpipes, and pre-applied thermal compound.
- It delivers excellent cooling efficiency with low noise, ideal for server and workstation environments.
Performance first- Combining our iconic fan colours with visually simple, nickel-plated heatsinks, our standard-line CPU coolers certainly stand out in a market where others focus on lighting effects and displays. Testament to our engineering-driven, “performance first” approach to product design, this iconic look has become symbolic of the superior cooling efficiency, excellent acoustics, industry-leading craftsmanship and unique longevity of Noctua CPU coolers.
Specifications
| General | Detailed Info |
|---|---|
| Socket Compatibility | LGA3647 |
| Total Height | 134 mm |
| Fan Configuration | 2x 92x92x25 mm NF-A9 HS-PWM |
| Fan Speed Range | 0 – 2500 rpm |
| Maximum Airflow | 96.3 m³/h (56.68 CFM) |
| Acoustical Noise | 30.6 dB(A) |
| Static Pressure | 3.26 mm H₂O |
| Rated Voltage | 12 V |
| Connector | 4-pin PWM |
| Colour | Brown |
| Number of Heatpipes | 4 |
| Heatpipe Diameter | 6 mm |
| Fin Count | 47 |
| Heatsink Base Material | Copper, nickel-plated |
| Heatsink Fin Material | Aluminium, nickel-plated |
| Heatpipe Material | Copper, nickel-plated |
| Interface Heatpipes/Fin | Soldered |
| Height with Fan(s) | 134 mm |
| Width with Fan(s) | 95 mm |
| Depth with Fan(s) | 120 mm |
| Weight with Fan(s) | 769 g |
| Rack Unit Compatibility | 4U, 5U |
| Base Size | 56 x 70 mm |
| Warranty | 6 years |
| Packaging Dimensions | 189 x 208 x 152 mm |
| Packaging Weight | 1426 g |
| EAN | 9010018000153 |
| UPC | 841501100154 |
