Description for Noctua NH-U14S TR4-SP3 Premium CPU Air Cooler for AMD sTRX4/TR4/SP3, 140mm Fan, Brown-CLR-0154
- The Noctua NH-U14S TR4-SP3 is a high-performance 140mm CPU air cooler engineered for AMD workstation and server sockets, offering efficient cooling,
- low noise operation, and premium build quality with a 6-year warranty.
Specifications
| General Info | Detailed Info |
|---|---|
| Socket Compatibility | TR4, sTRX4, SP3, sWRX8 |
| Total Height | 165 mm |
| Fan Model | NF-A15 HS-PWM |
| Fan Size | 140 x 150 x 25 mm (round) |
| Fan Speed Range | 0 – 1500 rpm |
| Maximum Airflow | 140.2 m³/h (82.52 CFM) |
| Maximum Noise Level | 24.6 dB(A) |
| Static Pressure | 2.08 mm H₂O |
| Rated Voltage | 12 V |
| Input Power | 1.19 W |
| Connector | 4-pin |
| Heatsink Material (Base) | Copper, nickel plated |
| Heatsink Fin Material | Aluminium, nickel plated |
| Heatpipe Material | Copper, nickel plated |
| Number of Heatpipes | 6 |
| Heatpipe Diameter | 6 mm |
| Fin Count | 56 |
| Weight With Fan | 1030 g |
| Weight Without Fan | 865 g |
| Width With / Without Fan | 150 mm |
| Depth With / Without Fan | 111 mm / 52 mm |
| Base Size | 56 x 70 mm |
| NSPR Rating | 162 |
| Rack Compatibility | 5U |
| Colour | Brown |
| Warranty | 6 Years |
| Packaging Dimensions | 217 x 226 x 113 mm |
| Packaging Weight | 1500 g |
| EAN | 9010018000108 |
| UPC | 841501100109 |
